Laser Welding Heads

Laser welding heads are compatible with a wide range of metals including stainless steel, carbon steel, aluminum, galvanized steel, copper, and various non-ferrous metal alloys. Different materials have varying maximum weld thicknesses—aluminum welds up to 5.5mm, copper up to 3mm, and galvanized sheet up to 6.5mm with the appropriate model selection.

Piranha laser welding heads are designed for ease of use, requiring only 1-2 hours of training for beginners to achieve professional-quality welds. The intuitive 7-inch LED touchscreen with 32 preset process parameters and multi-language interface simplifies operation. This dramatically reduces the learning curve compared to traditional TIG or MIG welding methods.

Yes, laser welding heads require industrial shielding gas—either argon or nitrogen—to protect the weld pool from oxidation and contamination. The proper gas selection depends on the material being welded. Argon is commonly used for stainless steel and aluminum, while nitrogen may be preferred for certain carbon steel applications to achieve specific metallurgical properties.

Laser welding offers four times faster welding speeds on mild steel, significantly smaller heat-affected zones that eliminate weld deformation and burn-through, and produces cleaner welds requiring little to no grinding or polishing. The process also reduces health risks by minimizing UV/IR radiation exposure and welding fumes compared to traditional arc welding methods.

Yes, Piranha laser welding heads include an integrated wire feeder module supporting 1.0mm, 1.2mm, and 1.6mm welding wire. This enables gap filling and achieving smooth, flush weld profiles even when fit-up tolerance is less than perfect. The combination of laser precision and wire feed provides excellent control for both autogenous welding and filler wire applications.

Laser welding heads are Class IV laser products requiring appropriate personal protective equipment. Laser-safe eyewear specifically rated for the laser wavelength is mandatory—safety goggles are included with every Piranha laser unit. Operators should also wear appropriate clothing to protect from reflected laser energy and follow all manufacturer safety protocols for Class IV laser operation.
